Description
| ANALYZER COMPARISON CHART | AMPRO plus #420082-01 |
AMPRO plus #420082-02 |
AMPRO plus #420082-03 |
AMPRO plus #420082-04 |
AMPRO plus #420082-05 |
AMPRO plus #420082-06 |
|---|---|---|---|---|---|---|
| AMPRO plus gas analyzer | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| DUAL Bluetooth for Android and iOS | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| O2 – Oxygen – Long Life sensor | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| CO2 – Carbon dioxide calculated | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| CO – Carbon monoxide | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| NO – Nitric oxide | ❌ | ❌ | ✅ | ✅ | ✅ | ✅ |
| NO2 – Nitrogen Dioxide | ❌ | ❌ | ❌ | ❌ | ✅ | ✅ |
| CALCULATED Nox | ❌ | ❌ | ✅ | ✅ | ❌ | ❌ |
| TRUE Nox | ❌ | ❌ | ❌ | ❌ | ✅ | ✅ |
| CO Sensor protection (active) | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Large fuel type list + user definable fuel types | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Combustion and Emission calculations | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Draft / Differential pressure | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Temperature / Differential temperature | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Color display 4″ | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Interfaces: Bluetooth, IRDA, USB, SD Card | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| High energy Li-lon battery (for up 20 hours operation time) | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Battery charger & USB cable | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Condensate separator with water stop filter | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| One additional replacement filter | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Transport Case standard | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Gas sampling line 9 foot | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Gas probe tube 12 inch with cone | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Speedprinter | ❌ | ✅ | ❌ | ✅ | ❌ | ✅ |
Features:
- Simultaneous measurement of up to 7 gas components.
- Suitable for emission monitoring of combustion and industrial processes.
- With up 7 true gas measurements
- NO and NO2 for true NOx measurements
- H2 compensate CO sensor
- Up to 20 hours operation time (Lithium Ion Battery)
- Low cost of ownership
- Extremely user friendly
- O2 sensor life expectancy + 4 years
- Active CO sensor protection
Benefits:
- Make your combustion process more cost-effective.
- Get the data to show your organization cares about the environment.
Applications:
boiler service, boiler trouble-shooting, burner efficiency, nox testing, breweries, cement industry, CO, CO2 calculated, CO2 measured, combustion handheld, CxHy, gas turbines / compressor, glass industry, installers / boiler manufacturers, iron / steel industry, NO, NO2, NOx, O2, power plants, refineries / petrochem, simple, SO2, universities / laboratory
The AMPRO plus is the replacement of the AMPRO 2000 – which was first introduced in 2010. This is the most versatile handheld gas analyzer in the world today. It has been constantly updated and upgraded over the years. The list of available options is enormous. Its ease of use and practicality makes this a great tool to use.
Here are some of the analyzer’s highlights:
A 4.0” crisp, clear color display with a zoom function makes it easy to read even under difficult circumstances. The measurement screen can be customized to your needs. You decide what you want to see and what values are important for you.
Simultaneous measurements of up to six gas components are possible. O2, CO, and calculated CO2 are standard. NO, NO2, SO2, and even measured CO2 can be added (even later).
With the standard probe, one can measure flue gas temperatures of up to 1,472 °F and 2,012 °F with an Inconel probe tube. Flue gas temperature and ambient air temperature are used to calculate combustion efficiency. The AMPRO plus also has a separate menu for differential temperature measurement, showing both measured values as well as the difference between both values.
During gas measurement, the analyzer also measures the draft in the stack. The AMPRO plus also has a separate menu for differential pressure measurement, showing both measured values as well as the difference between both values.
Measurements and be stored in the internal analyzer storage menu. Sixteen thousand data sets can be stored inside the analyzer. These have a date and time stamp, customer details, as well as the fuel type that has been used during the measurement. Multiple interfaces (USB/IR/SD card/Bluetooth/WLAN) are available to transfer data to either a printer or PC/laptop/smartphone.
With Bluetooth, the analyzer can be connected to your smartphone using the MRU4U app, which is available for Android and iOS. All measured values are displayed on your phone (tablet), and the measurement can be started/stopped remotely from your phone.
The internal lithium-ion battery allows twenty hours of operation time. The battery is charged using the USB port.
The gas conditioning system and sensor protection are also great features you wouldn’t want to miss. The large, easily accessible, and easy to empty condensate separator protects the analyzer from unwanted water (condensation) entering the analyzer. It has a built-in PTFE (Teflon) coated filter with excellent dirt removal capability. It is easy to replace and re-usable up to five times (after being washed).
The CO sensor protection is a great added feature, protecting your CO sensor from unwanted high CO concentrations (user-definable value). This will protect the CO sensor and extend the life span of the sensor.
The cost of ownership for the AMPRO plus is very low. Buying an analyzer is one thing, but how much do you have to spend over the years for service, calibration, and parts? Our analyzers are designed to last for years.
The AMPRO plus can be used as a combustion analyzer with O2, CO, and calculated CO2.
In most cases, it is used as a combustion/emission analyzer with TRUE NOx.
It’s your best choice for short-term (spot) measurements.
